Turbocharger 8972402101 RHF5 For Isuzu 4JA1 Engine

Description
Highlight:

8972402101 Turbocharger

,

Isuzu 4JA1 Turbocharger

,

Turbocharger 8972402101 RHF5

Product Details

Product Name: Diesel Engine Turbocharger

Main OEM Part Number: 8972402101

Model Type: RHF5 / VA420037

Fit Engine: Isuzu 4JA1, 4JA1L 2.5L Diesel Engine

Fit Equipment: Isuzu D-MAX pickup trucks, Isuzu ELF light trucks, small wheel loaders, compact excavators, agricultural tractors

Application Scenarios
  1. Light Commercial Vehicles: Isuzu D-MAX pickup, ELF light delivery trucks
  2. Construction Machinery: Mini wheel loaders, small engineering excavators
  3. Agricultural Equipment: Medium farm tractors, light harvesters
  4. Stationary Power: Small industrial backup diesel generator sets
Compatible Matching Table
Brand Engine Model Matching Turbo Part Number
ISUZU 4JB1 8973311850
Product Highlights
1. High-Temperature Ductile Cast Iron Single Volute Turbine Housing

Single channel nodular cast iron turbine shell with excellent thermal fatigue resistance. Stable under long continuous high exhaust temperature operation, anti-cracking and anti-deformation under frequent start-stop load changes of pickup trucks and light engineering vehicles.

2. Diaphragm Wastegate With Brass Pressure Chamber

Equipped with brass air pressure wastegate actuator with beige protective cover, automatically limits boost pressure to avoid overboost damage to engine internal components, maintains stable low-speed torque output under heavy load climbing and cargo haulage.

3. Precision Dynamic Balanced Aluminum Compressor Wheel

Aluminum alloy impeller undergoes high-speed dynamic balance calibration, high air intake efficiency. Significantly improves low-speed intake volume, enhances engine low-end torque, reduces black smoke during acceleration and full-load startup.

4. Full Floating Double Sliding Bearing + Multi-Layer High-Temp Composite Oil Seal

Dual full-floating sliding bearing matched with fluorine rubber high-temperature oil seals. Effectively suppress oil leakage risk, extend service life under all-day light-heavy duty operation, lower regular maintenance frequency.

5. 100% OEM Standard Mounting Interfaces

All exhaust flange, air inlet/outlet, oil supply and return ports fully consistent with original RHF5 turbocharger. Direct bolt-on replacement without cutting or modification, perfectly matched with Isuzu 4JA1 / 4JA1L engine.

Shipping

Multiple global air & sea freight shipping channels available. Each turbocharger is pre-oiled for anti-rust protection, packed with shockproof foam carton, complete factory inspection report and traceable tracking number for worldwide delivery.

Taxes

Import duties, local consumption taxes and customs handling fees are not included in quoted price and freight. Buyers shall bear all relevant fees in accordance with local customs regulations.

Product Advantage

This RHF5 wastegate turbocharger is customized for Isuzu 4JA1/4JA1L engine with OEM part number 8972402101, widely matched on Isuzu D-MAX pickups and ELF light trucks. It adopts high-temperature resistant cast iron turbine housing, brass pressure control actuator and precision balanced compressor wheel, fully meets OEM assembly calibration standard. It is a core overhaul replacement spare part, effectively shortening equipment downtime and reducing overall maintenance expenses.
